CONTROLS

Why invest in a control

  • Improved crop quality
  • Higher yield
  • Accurate Temp & RH
  • Negative Diff capabilities
  • Multiple Sensor Sites
  • Control Light, CO2, irrigation
  • Reduce energy consumption
  • Lower labor costs
  • Reduce chemical application costs
  • Increase longevity of equipment – Less wear and tear

Integrated Controls

  • Highly capable, designed to accommodate any growing situation, large or small.
  • Manages light, CO2, irrigation, outdoor sensors
  • Fertigation
  • Graphing, data logging
  • Each piece of equipment has individual settings, allowing it to act independently with greater efficiency

Staged Controls

  • Staged controls respond to changes in greenhouse temperature by activating groups or stages of heating and cooling equipment.
  • The groups of equipment respond collectively to drive the temperature to the desired value.
  • As the temperature moves further from the desired value, additional stages of equipment engage.

Staged Controls

Integrated Controls

STEP Up EnviroSTEP VersiSTEP Seed 16 Seed

Features

Number of zones 1 1 1 - 8 1 - many 1 - many
Number of outputs or stages 6 stages
2 heat & 4 cool
12 outputs 24 outputs 16 expandable to many with Seed I/O 24 expandable to many with Seed I/O
Setpoint Periods Day, night, DIF Day, night, DIF Day, night, DIF 4 setpoint periods 4 setpoint periods
Ramping Yes Yes Yes Yes Yes
Includes sensors & cables Aspirated temp sensor; Options RH sensor Aspirated & RH sensors; Additional sensors available No No No
Manual override Yes Yes Yes Yes Yes
Display Easy-to-read bright screen with full menu & LED lights Easy-to-read bright screen with full menu & LED lights Easy-to-read bright screen with full menu & LED lights Highly responsive touchscreen with Graphic User Interface Highly responsive touchscreen with Graphic User Interface
Logs & graphs Yes temp only Yes Yes Yes Yes
Equipment it controls Heating, cooling, vent & energy curtain Virtually any equipment Virtually any equipment Virtually any equipment Virtually any equipment
Light Dep No Yes Yes Yes Yes
Variable speed & modulating equipment Yes Yes Yes Yes Yes
Track Daily Light Integral No No No Yes Yes
Factors in outdoor humidity No No No Yes Yes
Light control No Yes Yes Yes Yes
Mist control No Yes Yes Yes Yes
Irrigation control No Yes Yes Yes Yes
CO2 control No Yes Yes Yes Yes
Increments vents Yes Yes Yes Yes Yes
Fertigation management No No No Yes - working with H.E. Anderson's J+ Link Technology Yes - working with H.E. Anderson's J+ Link Technology
Optional equipment
  • Weather Guard
  • STEP Up Compass software
  • Alarm Manager
  • Lightning Protector
  • Weather Station
  • STEPsaver software
  • Alarm Manager
  • Sensors: soil temp, light, hot water, CO2
  • Lightning Protector
  • Weather Station
  • STEPsaver software
  • Alarm Manager
  • Sensors: soil temp, light, hot water, CO2
  • 12-output Seed I/O Expansion
  • Sphere software
  • Weather Station
  • Alarm Manager
  • Sensors: soil temp, light, hot water, CO2
  • 12-output Seed I/O Expansion
  • Sphere software
  • Weather Station
  • Alarm Manager
  • Sensors: soil temp, light, hot water, CO2
Complete package
  • Aspirated temp sensor
  • 100' of cable
  • Override or Contactor Panel
  • Includes aspirated temp & RH sensor
  • 100' of cable

Staged Controls

Integrated Controls

Something new under the sun

Seed®



Explore the growing potential of our newest control
